Shops Erica Synths Polivoks VCO DIY Kit

The Kit version of the DIY VCO contains all the components needed for the module, including ICs, knobs, power cable, etc.

The core of shops the VCO is borrowed from the famous Russian synth Polivoks VCO and in exponential converter we use the original matched transistor IC that was used in Polivoks.

Features:

-Triangle, saw and pulse wave outputs
-Manually adjustable and CV controlled pulse width
-Great tracking across 8 octaves
-Exponential FM input with attenuator
-Synchronization input
-Octave switch – 5 octaves
-Skiff-friendly design

We have significantly updated schematics:

1. Introduced +-10V regulators for greater stability of operation,
2. Adjusted signal amplitudes to match requirements of contemporary modular synths and made all
output signals available simultaneously,
3. Redesigned CV inputs to accept positive CV signals,
4. Introduced PWM circuit with manual and  voltage controlled pulse width,
5. Introduced synchronization input, so you can sync the VCO to other VCOs.

This is a comparably complex DIY project for experienced builders. We do not recommend this for beginners and ones without proper soldering and testing equipment.

Technical specifications:

-Audio output amplitude: 10Vptp
-Octave range: C0 – C8
-Panel width: 12HP
-Module depth: 35mm
-Power consumption: 34mA@+12V, 36mA@-12V

Important links:
https://www.youtube.com/watch?v=ou9A9xgWmlM
https://www.youtube.com/watch?v=-UtbNXp-I90
Assembly guide/BOM: https://store.synthrotek.com/assets/images/Erica-Synths-Polivoks-VCO-Assembly-Guide.pdf
